New Holland Excel 9010

Key Features of New Holland Excel 9010

• No. Of Cylinder

  4
• Power

  90
• Capacity (cc)

  2900 CC
• PTO Power

  76.5
• Fuel Tank Capacity

  90 litre
• Lifting Capacity

  2500 Kg
• Wheel Drive

  4 WD

Specifications of New Holland Excel 9010

• Engine
  • Air Filter
    8" Dry type with dual element
  • Fuel Pump
    Rotary
  • Cooling Type
    Intercooler
  • No. Of Cylinder
    4
  • Engine Rated RPM
    2200 RPM
  • Capacity (cc)
    2900 CC
  • Power
    90

• Power Take Off (PTO) & Steering
  • PTO Power
    76.5
  • PTO RPM
    540 @ 2198 E RPM

• Transmission
  • Battery
    88 Ah
  • Clutch Type
    Double Clutch- Dry Friction Plate Wet Hydraulic Friction Plates Clutch
  • Gear Box
    12 Forward + 12 Reverse
  • Alternator
    55 AMP
  • Forward Speed
    0.29 - 37.43 kmph
  • Reverse Speed
    0.35 - 38.33 kmph

• Hydraulics & Brakes
  • Lifting Capacity
    2500 Kg
  • 3 point Linkage
    DRC valve & Isolator valve
  • Brakes
    Mechanically Actuated Oil Immersed Multi Disc

• Dimension & Capacity
  • Total Weight
    3120 / 3250 KG
  • Wheel Base
    2283 / 2259 MM
  • Fuel Tank Capacity
    90 litre

• Wheels & Tyres
  • Front Tyre Size
    12.4 X 24
  • Read Tyre Size
    18.4 X 30
  • Wheel Drive
    4 WD

• Others
  • Warranty
    6000 Hours or 6 Year
  • Options
    Creeper Speeds, Ground Speed PTO, Hydraulically Actuated Oil Immersed Multi Disc Brakes, 4 WD, RemoteValve with QRC, Swinging Drawbar, Additional Front and Rear CI Ballast, Foldable ROPS & Canopy, SKY WATCH, Power shuttle, Tiltable Steering Column
