Tata Signa 5530.S 4x2

Key Features of Tata Signa 5530.S 4x2

• Engine

  Cummins ISBe 6.7L BS6
• Power

  300
• GVW

  55000 KG
• Payload Capacity

  40000 KG

Specifications of Tata Signa 5530.S 4x2

• Performance
  • Max Speed
    80 KMPH
  • GVW
    55000 KG
  • Engine Cylinders
    6
  • Engine Norm
    BS-6 Phase 2
  • Payload Capacity
    40000 KG
  • Engine
    Cummins ISBe 6.7L BS6
  • Power
    300
  • Fuel Tank
    365 Ltrs.
  • Max Torque
    1100 Nm

• Dimensions
  • Wheelbase
    3300 MM

• Brakes Suspension
  • Rear Axle
    TATA Heavy Duty Single Reduction RA114
  • Rear Suspension
    Semi-elliptical multi leaf spring
  • Front Axle
    TATA 7T Reverse Elliot Type
  • Parking Brakes
    Yes
  • Brakes
    New iCGT Brakes
  • Abs
    No
  • Front Suspension
    Parabolic leaf spring

• Clutch Transmission
  • Clutch
    430 mm Dia Push type Single Plate Dry Friction Organic Lining
  • Gearbox
    TATA G1150 8F +1C + 1R Manual
  • Steering
    Power Steering
  • Power Steering
    Yes
  • Transmission
    Manual Synchromesh

• Body Cabin
  • Cabin Type
    Day and Slepper Cabin
  • Chassis Type
    Chassis with Cabin
  • Arm Rest
    No
  • Body Option
    Deck Body
  • Tiltable Cabin
    Yes
  • Seating Capacity
    Driver + 2 Passenger
  • Tiltable Steering
    Yes

• Tyre
  • Front Tyre
    295/90R20 Radial Tube
  • Rear Tyre
    295/90R20 Radial Tube
  • Tubeless Tyre
    Optional

• Others
  • Navigation System
    No
  • Telematics
    No
  • Cruise Control
    No
  • Air Condition
    No
  • Seat Belts
    Yes
  • Seat Type
    Standard
  • Hill Hold
    No
  • Fog Lights
    No
  • Driver Info Display
    Yes
  • Adjustable Driver Seat
    Yes
