Massey Ferguson 246 DYNATRACK 4WD

Key Features of Massey Ferguson 246 DYNATRACK 4WD

• No. Of Cylinder

  3
• Power

  46
• Capacity (cc)

  2700 CC
• PTO Power

  39
• Fuel Tank Capacity

  55 litre
• Lifting Capacity

  2050 Kg
• Wheel Drive

  4 WD

Specifications of Massey Ferguson 246 DYNATRACK 4WD

• Engine
  • No. Of Cylinder
    3
  • Power
    46
  • Capacity (cc)
    2700 CC
  • Cooling Type
    Water Cooled
  • Air Filter
    Wet Type
  • Fuel Pump
    Inline

• Power Take Off (PTO) & Steering
  • PTO Power
    39
  • PTO RPM
    540 RPM @ 1789 ERPM

• Transmission
  • Clutch Type
    Dual diaphragm clutch
  • Gear Box
    12 Forward + 12 Reverse
  • Battery
    12 V 80 Ah
  • Alternator
    12 V 36 A
  • Forward Speed
    34.5 kmph

• Hydraulics & Brakes
  • Brakes
    Multi disc oil immersed brakes
  • Lifting Capacity
    2050 Kg
  • 3 point Linkage
    Draft, position and response control. Links fitted with CAT-1 (Combi Ball)

• Dimension & Capacity
  • Fuel Tank Capacity
    55 litre
  • Total Weight
    2140 KG
  • Wheel Base
    2040 MM
  • Overall Length
    3642 MM
  • Overall Width
    1784 MM
  • Ground Clearance
    400 MM

• Wheels & Tyres
  • Wheel Drive
    4 WD
  • Front Tyre Size
    8.00 x 18
  • Read Tyre Size
    14.9 x 28

• Others
  • Warranty
    2000 Hours / 2 Year
