Volvo EC140DL

Key Features of Volvo EC140DL

Specifications of Volvo EC140DL

• General
  • Sub Category
    Excavator

• Engine
  • Displacement
    3.77 L
  • Engine Power
    105 Hp
  • Model
    EC140DL
  • Power ISO 14396
    0
  • Bore
    100 mm
  • Stroke
    120 mm

• Hydraulic System
  • Main system Maximum Flow
    118 Lpm

• Weights Operating
  • Weight
    16730 Kg
  • Operating Weight
    16730 Kg

• SERVICE REFILL CAPACITIES
  • Weights engine oil
    13.2 L
  • Weights hydraulic system including tank
    230 L
  • weights hydraulic tank
    85 L
  • Hydraulic System
    230 L

• Dimensions
  • Track Gauge
    1990 mm
  • Tail Swing Radius
    2200 mm
  • Track Length
    3760 mm
  • Counterweight Clearance
    920 mm
  • Ground Clearance
    436 mm

• WORKING RANGES & FORCES
  • Bucket Capacity
    0.66 Cum
  • Lifting Capacity
    3500 Kg
  • Maximum Digging Depth
    6030 MM
  • Maximum vertical wall digging depth
    5460 mm
