CASE 770 EX Magnum

Key Features of CASE 770 EX Magnum

Specifications of CASE 770 EX Magnum

• General
  • Sub Category
    Backhoe Loader

• Engine
  • Gross Power
    86 HP
  • Maximum Torque
    402 NM
  • Compliant
    BS-III
  • Model
    FPT S8000
  • Displacement
    3900 cc
  • Air Intake Type
    Turbocharged

• Hydraulic System
  • Pump Flow
    123 lpm
  • Pump type
    Gear Pump

• Power train
  • Powertrain Type
    4 forward and 4 reverse travel speeds with power Shuttle
  • Transmission make and model
    CARRARO 4WD TLB1

• Steering
  • System Pressure
    140 Bar
  • Unit Displacement
    125 CC
  • Type
    Power Steering

• Loader General Dimension
  • Bucket Capacity Std
    1.1 Cum
  • Dump Angle
    45 °
  • Hinge Pin Height
    3580 mm
  • Max Pay Load
    1760 Kg
  • Dump Height
    2732 mm
  • Load Over Height
    3275 mm
  • Reach At Ground
    1486 mm
  • Maximum Lifting Capacity
    3700 Kg

• Backhoe Loader Dimension
  • Bucket Rotation
    204 Degree
  • Safe Working Load
    1100 Kg
  • Reach ground level to Swing Center
    5753 mm
  • Max Working Height
    5593 mm
  • Max Load Over Height
    3774 mm
  • Bucket Breakout Force
    4535/5630 Kgf
  • dipper Tear Out Force
    3250/4300 Kgf
  • Maxd Dig Depth
    4547 mm

• Overall Dimension & Weight
  • Width Over Bucket
    2300 MM
  • Minimum Ground Clearance
    400 mm
  • Max Operating Weight
    8230 Kg
  • Transport Length
    2300 mm
  • Wheelbase
    2230 mm
  • Overall transport Height
    3840 mm

• Service Capacities
  • Hydraulic oil - System
    110 Ltr
  • Engine Oil
    9.1 Ltr
  • Coolant
    20 Ltr.
  • Fuel Tank
    129 Ltr
  • Rear Axle
    17 Ltr.
  • transmission Oil Capacitysystem
    22 Ltr.

• Axle
  • Rear
    Rigid axle with CARRARO 28.32M (2WD/4WD)
  • Front
    CNH PS1300 (2WD), Carraro 26.17 (4WD)
  • front axle Oscillation
    21 Degree (2WD), 16 Degree (4WD)

• Brakes
  • Brakes service
    Wet multi-discs
  • Brakes Parking
    Manual, with lever

• Tyre
  • HD tyre rear optional
    14X25 - 20 PR
  • Standard tyre front
    9.0x16 - 16 PR
  • standard tyre rear
    16.9x28 - 12 PR

• Electrical System
  • Battery
    12 V, 130 Ah

• Travel System
  • Forward
    6.2/10/20.7/39.2
  • Reverse
    7.4/12/Not Recommended
