CASE 770 NX

No reviews yet

Write a Review

The CASE 770 NX is a highly reliable and low-maintenance backhoe loader, ideal for a range of construction applications. It boasts a powerful 74 Hp engine and 275 NM torque, ensuring superior performance. With a bucket capacity of 0.26 Cum and a lifting capacity of 1417 Kg, it efficiently handles heavy materials. The 770 NX features a robust operating weight of 7600 Kg, ensuring stability, and offers a fuel tank capacity of 129 Ltr to reduce downtime. Its hydraulic system with 44 Ltr capacity enhances efficiency, while durable tyres ensure safety in demanding environments.

Price on Request^*

^*Prices are subjected to change

EMI ₹ 20,362 For 5 YearsEMI Calculator

Key Features of CASE 770 NX

Specifications of CASE 770 NX

General
- Sub Category
  Backhoe Loader
Engine
- Maximum Torque
  275 NM
- Model
  F28-CF28A001A*U
- Air Intake Type
  Turbocharged Intercooled
- Gross Power
  74 Hp
Hydraulic System
- System Type
  Open Center Load Sensing System
- Pump type
  Variable Displacement
- Pump Flow
  118 LPM
- System Relief Pressure
  240 Bar
Power train
- Transmission make and model
  CARRAO 2WD TLB1
Steering
- Turning Circle Diameter Otside Bucket
  4600 mm
- Turning circle Diameter Outside Bucket Not Braked
  5550 mm
- Type
  Power Steering
- System Pressure
  140 Bar
Loader General Dimension
- Dump Height
  2730 mm
- Load Over Height
  3300 mm
- Hinge Pin Height
  3600 mm
- Hinge Pin Forward Reach
  240 mm
- Reach At Ground
  1980 mm
- Max Reach At Full Height
  1190 mm
- Dump Angle
  45 °
- Bucket Capacity Std
  1100 Cum
Backhoe Loader Dimension
- Maxd Dig Depth
  4400 mm
- Reach ground level to Swing Center
  5630 mm
- Reach Ground level to rear wheel center
  6950 mm
- Reach at full height to slew center
  2150 mm
- Max Working Height
  5500 mm
- Max Load Over Height
  3600 mm
- Bucket Breakout Force
  204 kGf-5000/49 kN
- dipper Tear Out Force
  3200 kGf / 31 KN
Overall Dimension & Weight
- Max Operating Weight
  7600 Kg
Service Capacities
- Fuel Type
  Diesel
- Coolant
  10 L
- Hydraulic oil - System
  44 Ltr
- Engine Oil
  8.5 Ltr
- Rear Axle
  17.1 Leter
- Hydraulic Oil Replacement
  44 @ 4000 hrs
- transmission Oil Capacitysystem
  18 L
- Fuel Tank
  129 Ltr
Axle
- Rear
  CARRARO 2WD TLB1
- Front
  CNH PS1300
- front axle Oscillation
  21 Degree
Brakes
- Brakes service
  Hydraulic Foot Operated 2 Disc per side
- Brakes Parking
  Mechanical actuated calipper type brake pack on rear axle input shaft
Tyre
- Standard tyre front
  9 x 16 - 16 PR
- standard tyre rear
  16.9 X 28 - 12PR

CASE 770 NX Brochure

Download the brochure in just one click to view CASE 770 NX price, specs and features of all the variants.

CASE 770 NX images

CASE 770 NX User Reviews & Rating

This product has not been reviewed yet. Your opinion could help others

Your questions, answered

Can not find what you are looking for?

Ask our experts

What is the engine power of the CASE 770 NX?
The CASE 770 NX is equipped with a powerful engine delivering 74 Hp.
What is the bucket capacity of the CASE 770 NX?
The bucket capacity of the CASE 770 NX is 0.26 Cum.
What is the lifting capacity of the CASE 770 NX?
The lifting capacity of the CASE 770 NX is 1417 Kg.
How much does the CASE 770 NX weigh?
The operating weight of the CASE 770 NX is 7600 Kg.
What is the fuel tank capacity of the CASE 770 NX?
The fuel tank capacity of the CASE 770 NX is 129 Ltr.
What type of tyres does the CASE 770 NX use?
The CASE 770 NX uses 9 x 16 - 16 PR front tyres and 16.9 X 28 - 12PR rear tyres.
What is the hydraulic system capacity of the CASE 770 NX?
The hydraulic system of the CASE 770 NX has a capacity of 44 Ltr.
